Orionton BR-1064 II

Orionton BR-1064 II; Telefongyar, Terta (ID = 1465315) Radio
Orionton BR-1064 II; Telefongyar, Terta (ID = 742865) Radio Orionton BR-1064 II; Telefongyar, Terta (ID = 602844) Radio
Orionton BR-1064 II; Telefongyar, Terta (ID = 602845) Radio Orionton BR-1064 II; Telefongyar, Terta (ID = 602846) Radio
Orionton BR-1064 II; Telefongyar, Terta (ID = 602847) Radio Orionton BR-1064 II; Telefongyar, Terta (ID = 1991942) Radio
Use red slider bar for more.
Orionton BR-1064 II; Telefongyar, Terta (ID = 742865) Radio
Telefongyar, Terta: Orionton BR-1064 II [Radio] ID = 742865 933x670
Select picture or schematic to display from thumbnails on the right and click for download.
For model Orionton BR-1064 II, Telefongyar, Terta (TRT); Budapest:
Thanks for Mr.Herczeg István Hungary! Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Telefongyar, Terta (TRT); Budapest
Brand

Terta, TRT
Year: 1964–1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 2SA12 2SA12 2SA58 OC1075 OC1075 OC1074 OC1074
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Orionton BR-1064 II - Telefongyar, Terta TRT;
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 180 x 80 mm / 9.4 x 7.1 x 3.1 inch
Notes Marine band:33-94 m.
Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)
Literature/Schematics (1) Radio es Televizio Vevö keszülekek 1964-66

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
