For model 3-Way Speaker System HL 800, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Telefunken Katalog 1985

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1984 ? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: 3-Way Speaker System HL 800 - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 275 x 455 x 250 mm / 10.8 x 17.9 x 9.8 inch
Notes

Telefunken 3-Way 3-Speaker System Model HL 800.
50 Watts Sinus
80 Watts Music Power
Impedance 8 Ohms
40 - 20000Hz
Drivers:
1x Woofer 213mm
1x MidRange 105mm
1x Tweeter 12mm
Finish:
Metallic-Brown



Mentioned in -- Original prospect or advert (Telefunken Programm 1985)

Model page created by Franz Scharner. See "Data change" for further contributors.
