9A/W (T9A/W)

9A/W ; Telefunken (ID = 88850) Radio

9A/W ; Telefunken (ID = 88853) Radio

9A/W ; Telefunken (ID = 88851) Radio

9A/W ; Telefunken (ID = 88852) Radio
9A/W ; Telefunken (ID = 82350) Radio
Use red slider bar for more.
9A/W ; Telefunken (ID = 82350) Radio
Telefunken: 9A/W [Radio] ID = 82350 466x605
Select picture or schematic to display from thumbnails on the right and click for download.
For model 9A/W (T9A/W), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1930–1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: REN1004 REN1004 REN1004 REN1004 RE304 RGN1054
Main principle TRF with regeneration; 2 Special; 2 AF stage(s); Neutrodyne
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: 9A/W - Telefunken Deutschland TFK,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 620 x 800 x 400 mm / 24.4 x 31.5 x 15.7 inch
Notes Entspricht dem 9A (Variante Netz) mit Endröhre RE304, Körting-Netzgerät ANWL und Lautsprecher-Schrank als Unterbau.
Price in first year of sale 440.00 RM !
Source of data Katalog Radio-Zentrale Prohaska 1930/31 (dick) / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Arlt's grosser Radiokatalog 1930 (Radio-Schnorr Katalog 1931/32)


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
