Antennen-Diversity-Gerät Abl.127
Use red slider bar for more.
Telefunken: Antennen-Diversity-Gerät Abl.127 [Misc] ID = 112741 640x426
Select picture or schematic to display from thumbnails on the right and click for download.
For model Antennen-Diversity-Gerät Abl.127, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
|
|
Year:
1959 ??
|
Category: Miscellaneous (Other, Various) - see notes |
Semiconductors (the count is only for transistors) |
17:
|
Main principle |
Radio Frequency Amplification only; ZF/IF 525 kHz; Special type of reception - please describe.
|
Wave bands |
Broadcast and Short Wave (SW). |
Details |
|
Power type and voltage |
Alternating Current supply (AC) / 110 - 240 Volt |
Loudspeaker |
|
Power out |
|
from Radiomuseum.org |
Model: Antennen-Diversity-Gerät Abl.127 - Telefunken Deutschland TFK, |
Material |
Metal case |
Shape |
Tablemodel, with any shape - general. |
Dimensions (WHD) |
275 x 110 x 310 mm / 10.8 x 4.3 x 12.2 inch |
Notes |
Antennen-Diversity-Gerät für E127 oder andere Empfänger mit ZF von 525 kHz. Schaltet von zwei bzw. drei Antennen automatisch diejenige ein, dessen Eingangssignal am stärksten ist. Manueller Betrieb ebenfalls möglich. Anwendung durch professionelle Funkdienste und Bundeswehr. |
Net weight (2.2 lb = 1 kg) |
10 kg / 22 lb 0.4 oz (22.026 lb) |
