Automatischer Telefon-Anrufbeantworter T104
Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
- Country
- Germany
- Manufacturer / Brand
- Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
- Year
- 1967–1971
- Category
- Telephony - wire and wireless
- Radiomuseum.org ID
- 27212
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Automatischer Telefon-Anrufbeantworter T104 - Telefunken Deutschland TFK,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 270 x 185 x 110 mm / 10.6 x 7.3 x 4.3 inch
- Notes
- Gesprächszähler, Durchsagebetrieb bis 60 sek. (Endlos-Bandkassette), 9,5 cm/s. Gesprächsaufzeichnung in Verbindung mit Tonband-oder Diktiergerät.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- External source of data
- erb
- Source of data
- Handbuch VDRG 1967/1968
- Mentioned in
- -- Original prospect or advert
