Digitale CR 600

Digitale CR 600; Telefunken (ID = 183942) Radio

Digitale CR 600; Telefunken (ID = 183946) Radio

Digitale CR 600; Telefunken (ID = 183951) Radio

Digitale CR 600; Telefunken (ID = 183953) Radio

Digitale CR 600; Telefunken (ID = 183956) Radio

Digitale CR 600; Telefunken (ID = 183958) Radio

Digitale CR 600; Telefunken (ID = 183979) Radio

Digitale CR 600; Telefunken (ID = 183980) Radio

Digitale CR 600; Telefunken (ID = 183981) Radio

Digitale CR 600; Telefunken (ID = 183982) Radio
Digitale CR 600; Telefunken (ID = 2277344) Radio Digitale CR 600; Telefunken (ID = 2277343) Radio
Digitale CR 600; Telefunken (ID = 2277345) Radio Digitale CR 600; Telefunken (ID = 2277346) Radio
Digitale CR 600; Telefunken (ID = 2277347) Radio Digitale CR 600; Telefunken (ID = 2277348) Radio
Digitale CR 600; Telefunken (ID = 1139925) Radio Digitale CR 600; Telefunken (ID = 183948) Radio
Digitale CR 600; Telefunken (ID = 1139926) Radio Digitale CR 600; Telefunken (ID = 1139927) Radio
Use red slider bar for more.
Digitale CR 600; Telefunken (ID = 2277344) Radio
Telefunken: Digitale CR 600 [Radio] ID = 2277344 1400x894
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digitale CR 600, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: BF241 2SC461 2SA673 2SD468 2SB562 2SB562 2SC459 2SC1214 TDA1220 TDA1054 TBA820 HD38991
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     6 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Digitale CR 600 - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 320 x 92 x 200 mm / 12.6 x 3.6 x 7.9 inch
Notes .
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
