Famulus 7481T

Famulus 7481T; Telefunken (ID = 1940045) Radio

Famulus 7481T; Telefunken (ID = 1940046) Radio

Famulus 7481T; Telefunken (ID = 1940047) Radio

Famulus 7481T; Telefunken (ID = 1940048) Radio

Famulus 7481T; Telefunken (ID = 1940049) Radio

Famulus 7481T; Telefunken (ID = 1940050) Radio
Use red slider bar for more.
Famulus 7481T; Telefunken (ID = 1940045) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: OC614 OC614 AF105a AF105 AC122 AC122 AC117 AC117
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Famulus 7481T - Telefunken Deutschland TFK,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 135 x 58 mm / 9.4 x 5.3 x 2.3 inch
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Price in first year of sale 185.00 DM
Source of data Handbuch VDRG 1963/1964 / Radiokatalog Band 1, Ernst Erb
Mentioned in Handbuch RFP 1963
