FE20/53TM
Use red slider bar for more.
Telefunken: FE20/53TM [Television] ID = 293945 634x506
Select picture or schematic to display from thumbnails on the right and click for download.
For model FE20/53TM, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
|
|
Year:
1959/1960
|
Category: Television Receiver (TV) or Monitor |
Valves / Tubes |
22:
AW53-88
|
Main principle |
Superheterodyne (common); ZF/IF 38900 kHz
|
Wave bands |
Wave Bands given in the notes. |
Details |
Radio Control (+Remote Wire etc) |
Power type and voltage |
Alternating Current supply (AC) / 220 Volt |
Loudspeaker |
2 Loudspeakers |
Power out |
|
from Radiomuseum.org |
Model: FE20/53TM - Telefunken Deutschland TFK, |
Material |
Wooden case |
Shape |
Tablemodel, low profile (big size). |
Dimensions (WHD) |
670 x 510 x 410 mm / 26.4 x 20.1 x 16.1 inch |
Notes |
Technische Daten wie FE20/53T, jedoch zusätzlich Motor-Kanalschalter mit Vorwahl und UHF-Kanalanzeige. Mehrpreis für eingebauten UHF-Tuner: 110,- DM. |
Price in first year of sale |
1'058.00 DM |
Source of data |
HdB d.Rdf-& Ferns-GrH 1959/60 |
Model page created by Bernd P. Kieck. See "Data change" for further contributors.
