FE24S 53 cm

FE24S; Telefunken (ID = 1280447) Television

FE24S; Telefunken (ID = 1280450) Television

FE24S; Telefunken (ID = 1435592) Television
FE24S; Telefunken (ID = 1280364) Television
Use red slider bar for more.
FE24S; Telefunken (ID = 1280364) Television
Telefunken: FE24S [Television] ID = 1280364 568x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model FE24S 53 cm, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Q: Telefunken, Service-Unterlagen

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1960/1961 Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: AW53-88
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: FE24S [53 cm] - Telefunken Deutschland TFK,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 630 x 900 x 440 mm / 24.8 x 35.4 x 17.3 inch
Notes VHF; UHF-Automatik gegen Mehrpreis (114,- DM), dann 21 Röhren.
Net weight (2.2 lb = 1 kg) 53.5 kg / 117 lb 13.5 oz (117.841 lb)
Price in first year of sale 1'128.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1960/61

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
