HF-Relaisschiene Rs 356/1

HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357891) Misc

HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357893) Misc

HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357895) Misc

HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357896) Misc
HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357889) Misc HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357890) Misc
Use red slider bar for more.
HF-Relaisschiene Rs 356/1; Telefunken (ID = 1357889) Misc
Telefunken: HF-Relaisschiene Rs 356/1 [Misc] ID = 1357889 800x400
Select picture or schematic to display from thumbnails on the right and click for download.
For model HF-Relaisschiene Rs 356/1, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Telefunken-Prospekt

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1956 Category: Miscellaneous (Other, Various) - see notes
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Powered by external power supply or a main unit. / 24 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: HF-Relaisschiene Rs 356/1 - Telefunken Deutschland TFK,
Material Metal case
Shape Rack
Dimensions (WHD) 520 x 66 x 200 mm / 20.5 x 2.6 x 7.9 inch
Notes

Relaisschiene zur Auswahl von Empfangsantennen durch einen Wahlschalter vom Arbeitsplatz aus.

Einschub für Gestelleinbau.

Source of data -- Original prospect or advert

Model page created by Rudolf Müller. See "Data change" for further contributors.
