• Year
  • 1979
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 136038

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Hifi Stereo Cassette Deck TC 450 - Telefunken Deutschland TFK,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 460 x 145 x 280 mm / 18.1 x 5.7 x 11 inch
  • Notes
  • Telefunken Hifi Stereo Cassette Deck TC 450; HighCom, bis zu 30 - 15.000 Hz, Hard Permalloy Kombikopf, Bandzählwerk, 2 VU-Anzeigen, Buchsen für Mikrofon und Kopfhörer, Gehäuseausführungen: metallic-braun oder mattschwarz mit champagner-metallic Frontblende.

    Type: 2-head, single compact cassette deck
    Track System: 4-track, 2-channel stereo
    Tape Speed: 4.75 cm/s
    Heads: 1 x record/playback, 1 x erase
    Tape selector: type I, FeCr, CrO2
    Noise Reduction: HighCom
    Frequency Response: 30 Hz to 15 kHz (CrO2 tape)
    Signal to Noise Ratio: 74 dB (HighCom)

  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • Katalog Deutschland ~1979
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
