• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1963 ?

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 231744

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Ladegerät L-193/1 - Telefunken Deutschland TFK,

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Dimensions (WHD)
• 365 x 200 x 315 mm / 14.4 x 7.9 x 12.4 inch

• Notes

• Ladegerät für 24 V-Akkumulatoren und Stromversorgung für militärische Funkgeräte.

  Ausgangsleistung 24 V, 5 A.

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Author
• Model page created by Siegfried Droese. See "Data change" for further contributors.
