• Year
  • 1973 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 114202

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Power out
  • 4 W (unknown quality)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: M410 - Telefunken Deutschland TFK,
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 410 x 155 x 350 mm / 16.1 x 6.1 x 13.8 inch
  • Notes
  • Vierspur-Mono-Tonbandgerät. Bandgeschwindigkeit: 9,53 cm/s, Übertragungsbereich: 63···12500 Hz. Eingänge für Mikrofon, Plattenspieler, Radio. Ausgang für Verstärker: 1,2 V/12 kOhm; Ausgangsleistung 4 W Sinus bzw. 5 W Musik.
  • Net weight (2.2 lb = 1 kg)
  • 11 kg / 24 lb 3.7 oz (24.229 lb)
  • Author
  • Model page created by Wolfgang Lill. See "Data change" for further contributors.
