Magnetophon 295K

Magnetophon 295K; Telefunken Italia, (ID = 2154034) R-Player Magnetophon 295K; Telefunken Italia, (ID = 2154037) R-Player
Magnetophon 295K; Telefunken Italia, (ID = 2154039) R-Player Magnetophon 295K; Telefunken Italia, (ID = 2154042) R-Player
Magnetophon 295K; Telefunken Italia, (ID = 2154044) R-Player
Use red slider bar for more.
Magnetophon 295K; Telefunken Italia, (ID = 2154034) R-Player
Telefunken Italia,: Magnetophon 295K [R-Player] ID = 2154034 1400x1867
Select picture or schematic to display from thumbnails on the right and click for download.
For model Magnetophon 295K, Telefunken Italia, Milano

Country:  Italy
Manufacturer / Brand:  Telefunken Italia, Milano
Year: 1960 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes unknown_Tube EM84
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 125; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Magnetophon 295K - Telefunken Italia, Milano
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 410 x 170 x 360 mm / 16.1 x 6.7 x 14.2 inch
Notes

TELEFUNKEN Magnetophon mod. 295K - controllo volume/tono - tasti riprod./reg./stop/stop rap./sic.reg./mix/rf/micro/ff.ww:rew.  - counter avanzamento nastro - indicatore segnale di registrazione - ingressi Phono/Micro/Radio - regolazione sensibilità microfono - regolazione ingresso phono/radio - ingresso alta impedenza - commutatore altoparlante incluso/escluso - presa per altoparlante esterno.

Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
