Magnetophon 401

Magnetophon 401; Telefunken (ID = 96816) R-Player
Magnetophon 401; Telefunken (ID = 756786) R-Player Magnetophon 401; Telefunken (ID = 96819) R-Player
Magnetophon 401; Telefunken (ID = 529016) R-Player Magnetophon 401; Telefunken (ID = 878644) R-Player
Magnetophon 401; Telefunken (ID = 878645) R-Player Magnetophon 401; Telefunken (ID = 878661) R-Player
Magnetophon 401; Telefunken (ID = 878683) R-Player Magnetophon 401; Telefunken (ID = 878705) R-Player
Magnetophon 401; Telefunken (ID = 878726) R-Player Magnetophon 401; Telefunken (ID = 1466511) R-Player
Use red slider bar for more.
Magnetophon 401; Telefunken (ID = 756786) R-Player
Telefunken: Magnetophon 401 [R-Player] ID = 756786 704x650
Select picture or schematic to display from thumbnails on the right and click for download.
For model Magnetophon 401, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Q: Telefunken Service

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1965–1967 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 12: AC161 AC170 AC170 AC171 AC117 AC117 AC117 AC117 AC117 AC122 BFY39 BFY39
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Magnetophon 401 - Telefunken Deutschland TFK,
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 292 x 205 x 93 mm / 11.5 x 8.1 x 3.7 inch
Notes Cassettengerät nach System "DC-International"; Zweispur-Mono; Frequenzbereich: 40···10000 Hz; externe Stromversorgung möglich.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1965/1966
Mentioned in Handbuch VDRG 1966/1967
