Mozart FA-1886

Mozart FA-1886; Telefunken (ID = 279865) Radio

Mozart FA-1886; Telefunken (ID = 279866) Radio

Mozart FA-1886; Telefunken (ID = 279867) Radio

Mozart FA-1886; Telefunken (ID = 279868) Radio

Mozart FA-1886; Telefunken (ID = 279869) Radio

Mozart FA-1886; Telefunken (ID = 257775) Radio
Mozart FA-1886; Telefunken (ID = 263668) Radio Mozart FA-1886; Telefunken (ID = 1166137) Radio
Mozart FA-1886; Telefunken (ID = 1166138) Radio Mozart FA-1886; Telefunken (ID = 1166139) Radio
Mozart FA-1886; Telefunken (ID = 1166140) Radio Mozart FA-1886; Telefunken (ID = 1166141) Radio
Use red slider bar for more.
Mozart FA-1886; Telefunken (ID = 263668) Radio
Telefunken: Mozart FA-1886 [Radio] ID = 263668 605x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mozart FA-1886, Telefunken Radiotécnica Ibérica; Getafe

Country:  Spain
Manufacturer / Brand:  Telefunken Radiotécnica Ibérica; Getafe
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UF41 UAF42 UL84 DM70 UY41
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110-125 Volt
Loudspeaker 2 Loudspeakers / Ø 16.5 cm = 6.5 inch
Power out
from Radiomuseum.org Model: Mozart FA-1886 - Telefunken Radiotécnica
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes

Monta tocadiscos Telefunken TZ de tres velocidades (33, 45, 78) con doble aguja de zafiro.

2º altavoz = 10 cm. (2nd loudspeaker = 10 cm.)

Price in first year of sale 6'750.00
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Jose Antonio Gonzalez-Ruiz. See "Data change" for further contributors.
