Musikus 108VX

Musikus 108VX; Telefunken (ID = 379034) R-Player

Musikus 108VX; Telefunken (ID = 379033) R-Player

Musikus 108VX; Telefunken (ID = 379035) R-Player

Musikus 108VX; Telefunken (ID = 2086747) R-Player

Musikus 108VX; Telefunken (ID = 2086748) R-Player
Musikus 108VX; Telefunken (ID = 354676) R-Player Musikus 108VX; Telefunken (ID = 2086749) R-Player
Use red slider bar for more.
Musikus 108VX; Telefunken (ID = 354676) R-Player
Telefunken: Musikus 108VX [R-Player] ID = 354676 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikus 108VX, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1969–1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 4: AC122 AC122 AC124 AC124
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Musikus 108VX - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 355 x 155 x 270 mm / 14 x 6.1 x 10.6 inch
Notes 4 Geschwindigkeiten; Kristallsystem T23/1 mit Saphir A23/1.
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Source of data Handbuch VDRG 1969/1970
Mentioned in -- Original-techn. papers.

Model page created by Hans van der Marel. See "Data change" for further contributors.
