Musikus 108V

Musikus 108V; Telefunken (ID = 444992) R-Player Musikus 108V; Telefunken (ID = 537362) R-Player
Musikus 108V; Telefunken (ID = 537368) R-Player Musikus 108V; Telefunken (ID = 537356) R-Player
Musikus 108V; Telefunken (ID = 537358) R-Player Musikus 108V; Telefunken (ID = 537360) R-Player
Musikus 108V; Telefunken (ID = 537365) R-Player Musikus 108V; Telefunken (ID = 537367) R-Player
Musikus 108V; Telefunken (ID = 1244463) R-Player Musikus 108V; Telefunken (ID = 1244464) R-Player
Use red slider bar for more.
Musikus 108V; Telefunken (ID = 444992) R-Player
Telefunken: Musikus 108V [R-Player] ID = 444992 850x642
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikus 108V, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1967–1969 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 4: AC122 AC122 AC124 AC124
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Musikus 108V - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 320 x 160 x 260 mm / 12.6 x 6.3 x 10.2 inch
Notes 4 Geschwindigkeiten; Kristallsystem T23/1 mit Saphir A23/1.
Net weight (2.2 lb = 1 kg) 4.6 kg / 10 lb 2.1 oz (10.132 lb)
Price in first year of sale 190.00 DM
Collectors' prices
Source of data Handbuch VDRG 1967/1968

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
