Netz-/Ladegerät NV60

Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Data
Forum
Pictures
Collections

  • Year
  • 1981 ?
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 313652

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Power: Charger for A-Batteries
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Netz-/Ladegerät NV60 - Telefunken Deutschland TFK,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 150 x 100 x 305 mm / 5.9 x 3.9 x 12 inch
  • Notes

  • Leistungsaufnahme 70 Watt
    Betriebsspannung für Rekorder VRV-610     12 V DC
    Ladestrom für Akku NC50  max. 1,8 A

    Fest angeschlossene Verbindungsleitung zum VRV-610

  • Net weight (2.2 lb = 1 kg)
  • 3.6 kg / 7 lb 14.9 oz (7.93 lb)
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Heinz Unsöld. See "Data change" for further contributors.
