Regös 1213

Regös 1213; Telefunken; Budapest (ID = 138227) Radio
Regös 1213; Telefunken; Budapest (ID = 2213056) Radio Regös 1213; Telefunken; Budapest (ID = 2213057) Radio
Regös 1213; Telefunken; Budapest (ID = 1198513) Radio Regös 1213; Telefunken; Budapest (ID = 585832) Radio
Regös 1213; Telefunken; Budapest (ID = 644255) Radio Regös 1213; Telefunken; Budapest (ID = 504881) Radio
Regös 1213; Telefunken; Budapest (ID = 644257) Radio Regös 1213; Telefunken; Budapest (ID = 132637) Radio
Regös 1213; Telefunken; Budapest (ID = 474439) Radio Regös 1213; Telefunken; Budapest (ID = 644651) Radio
Use red slider bar for more.
Regös 1213; Telefunken; Budapest (ID = 2213056) Radio
Telefunken; Budapest: Regös 1213 [Radio] ID = 2213056 1176x1314
Select picture or schematic to display from thumbnails on the right and click for download.
For model Regös 1213, Telefunken; Budapest:
Perneky Sándor - Rádiómúzeum Alapítvány, Verőce, Hungary, radiomuzeum.hu

Country:  Hungary
Manufacturer / Brand:  Telefunken; Budapest
Year: 1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: AF7 AL1 AZ1
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Regös 1213 - Telefunken; Budapest
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 338 x 385 x 200 mm / 13.3 x 15.2 x 7.9 inch
Price in first year of sale 166.00 Pengö
Source of data -- Collector info (Sammler)
Mentioned in Rádiókészülékek Kapcsolásai 1936-56

Model page created by Folkert Rothe. See "Data change" for further contributors.



All listed radios etc. from Telefunken; Budapest
Here you find 91 models, 87 with images and 63 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
