Romancero 954AC

Romancero 954AC; Telefunken (ID = 216008) Radio

Romancero 954AC; Telefunken (ID = 235223) Radio

Romancero 954AC; Telefunken (ID = 273086) Radio

Romancero 954AC; Telefunken (ID = 273087) Radio

Romancero 954AC; Telefunken (ID = 273088) Radio

Romancero 954AC; Telefunken (ID = 273089) Radio

Romancero 954AC; Telefunken (ID = 273090) Radio

Romancero 954AC; Telefunken (ID = 1693971) Radio

Romancero 954AC; Telefunken (ID = 1727855) Radio
Romancero 954AC; Telefunken (ID = 813558) Radio Romancero 954AC; Telefunken (ID = 813565) Radio
Romancero 954AC; Telefunken (ID = 813563) Radio Romancero 954AC; Telefunken (ID = 229284) Radio
Romancero 954AC; Telefunken (ID = 813559) Radio Romancero 954AC; Telefunken (ID = 813560) Radio
Romancero 954AC; Telefunken (ID = 813561) Radio Romancero 954AC; Telefunken (ID = 813564) Radio
Romancero 954AC; Telefunken (ID = 992486) Radio Romancero 954AC; Telefunken (ID = 1165967) Radio
Use red slider bar for more.
Romancero 954AC; Telefunken (ID = 813558) Radio
Telefunken: Romancero 954AC [Radio] ID = 813558 480x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model Romancero 954AC, Telefunken Radiotécnica Ibérica; Getafe

Country:  Spain
Manufacturer / Brand:  Telefunken Radiotécnica Ibérica; Getafe
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH41 UAF41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 468 kHz; 2 AF stage(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Romancero 954AC - Telefunken Radiotécnica
Material Bakelite case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Price in first year of sale 1'190.00 Ptas
Literature/Schematics (1) -- Schematic

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.



All listed radios etc. from Telefunken Radiotécnica Ibérica; Getafe
Here you find 371 models, 286 with images and 263 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
