Sperrkreis Rfz15

Sperrkreis Rfz15; Telefunken (ID = 75280) mod-past25 Sperrkreis Rfz15; Telefunken (ID = 652163) mod-past25
Sperrkreis Rfz15; Telefunken (ID = 652162) mod-past25 Sperrkreis Rfz15; Telefunken (ID = 652161) mod-past25
Use red slider bar for more.
Sperrkreis Rfz15; Telefunken (ID = 75280) mod-past25
Telefunken: Sperrkreis Rfz15 [mod-past25] ID = 75280 600x616
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sperrkreis Rfz15, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Telefunken Sperrkreis Rfz15

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1931 ? Category: Radio module post 1925 (not a part, not a key)
Main principle RF-Circuit or wave trap (separate, can also be an antenna with amp.)
Tuned circuits 1 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Sperrkreis Rfz15 - Telefunken Deutschland TFK,
Material Bakelite case
Dimensions (WHD) 158 x 110 x 0 mm / 6.2 x 4.3 x 0 inch
Notes Unterdrückt störende Wellen und ermöglicht auch in der Nähe starker Sender störungsfreien Fernempfang. Wellenbereich 200...640 m.
Net weight (2.2 lb = 1 kg) 0.470 kg / 1 lb 0.6 oz (1.035 lb)
Price in first year of sale 40.00 ATS

Model page created by Peter Gölles. See "Data change" for further contributors.
