For model star clock 101, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
eBay-Artikelnummer: 331563716993 newash1

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1974–1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: star clock 101 - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 280 x 95 x 132 mm / 11 x 3.7 x 5.2 inch
Notes

Klappzahlen-Uhr. Gehäusefarben: mattschwarz/silber oder perlweiss.

Kataloge, Hersteller-Prospekte und Service-Unterlagen nennen das Modell Star Clock 101, Geräte selbst sind dagegen nur mit Star Clock bezeichnet

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
External source of data Erb
Source of data Katalog RFP 1974
Mentioned in Funk-Technik (FT) (9/1974, S. 327 / Werbeanzeige)
Literature/Schematics (1) -- Original-techn. papers.
