Telefunken: TD14 [Microphone/PU] ID = 641521 800x650
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1972 ?? | Category: Microphone or Pick-up element |
| Wave bands | - without |
|---|---|
| Details | |
| Power type and voltage | No Power needed |
| Loudspeaker | - For headphones or amp. |
| Power out | |
| from Radiomuseum.org | Model: TD14 - Telefunken Deutschland TFK, |
| Material | Plastics (no bakelite or catalin) |
| Shape | Miscellaneous shapes - described under notes. |
| Dimensions (WHD) | 21 x 21 x 137 mm / 0.8 x 0.8 x 5.4 inch |
| Notes | Dynamisches Mikrofon mit ein/aus-Schalter für Hand oder Tischverwendung, (Aufsteckspange aus Metall bei Tischbetrieb),Anschlußstecker: Mikrofon Din 3-pol/ DS001, Schalter Din 5-pol/DS003/240°, Länge des Anschlußkabels 1,5mtr |
| Net weight (2.2 lb = 1 kg) | 0.050 kg / 0 lb 1.8 oz (0.11 lb) |
Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
