TW562

TW562; Telefunken (ID = 295204) R-Player TW562; Telefunken (ID = 294203) R-Player
TW562; Telefunken (ID = 551410) R-Player TW562; Telefunken (ID = 551411) R-Player
TW562; Telefunken (ID = 551412) R-Player TW562; Telefunken (ID = 551413) R-Player
TW562; Telefunken (ID = 1053551) R-Player TW562; Telefunken (ID = 1053552) R-Player
TW562; Telefunken (ID = 2254576) R-Player TW562; Telefunken (ID = 2350712) R-Player
Use red slider bar for more.
TW562; Telefunken (ID = 295204) R-Player
Telefunken: TW562 [R-Player] ID = 295204 786x596
Select picture or schematic to display from thumbnails on the right and click for download.
For model TW562, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
From a Portuguese Prospect

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1958–1960 Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: TW562 - Telefunken Deutschland TFK,
Shape Chassis only or for «building in»
Dimensions (WHD) 360 x 242 x 302 mm / 14.2 x 9.5 x 11.9 inch
Notes 4 Geschwindigkeiten; Kristall-System, 30-14000 Hz. Auch mit Zarge (DM 18,-) lieferbar.
Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Price in first year of sale 148.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1958/59


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3460 models, 3030 with images and 2006 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
