Capricho 1651-U
Telefunken Radiotécnica Ibérica; Getafe
- Country
- Spain
- Manufacturer / Brand
- Telefunken Radiotécnica Ibérica; Getafe
- Year
- 1952
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 62547
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 468 kHz; 2 AF stage(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- AC/DC-set / 110-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Capricho 1651-U - Telefunken Radiotécnica
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 305 x 252 x 164 mm / 12 x 9.9 x 6.5 inch
- Net weight (2.2 lb = 1 kg)
- 3.730 kg / 8 lb 3.5 oz (8.216 lb)
- Price in first year of sale
- 2,300.00 ESP
- External source of data
- Ernst Erb
- Source of data
- Radio Historia y Técnica, J.J.E.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (4)
- Anuncio La Vanguardia Española Octubre 1951 modelos para 1952
