UHF-Converter UV2

UHF-Converter UV2; Telefunken (ID = 411196) Converter
UHF-Converter UV2; Telefunken (ID = 443922) Converter UHF-Converter UV2; Telefunken (ID = 223763) Converter
UHF-Converter UV2; Telefunken (ID = 223764) Converter UHF-Converter UV2; Telefunken (ID = 204695) Converter
UHF-Converter UV2; Telefunken (ID = 981456) Converter UHF-Converter UV2; Telefunken (ID = 1319496) Converter
UHF-Converter UV2; Telefunken (ID = 1319497) Converter UHF-Converter UV2; Telefunken (ID = 1319498) Converter
UHF-Converter UV2; Telefunken (ID = 1319499) Converter UHF-Converter UV2; Telefunken (ID = 1319500) Converter
Use red slider bar for more.
UHF-Converter UV2; Telefunken (ID = 443922) Converter
Telefunken: UHF-Converter UV2 [Converter] ID = 443922 541x282
Select picture or schematic to display from thumbnails on the right and click for download.
For model UHF-Converter UV2, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1962/1963 Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Valves / Tubes 2: EC86 EC88
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: UHF-Converter UV2 - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 260 x 75 x 190 mm / 10.2 x 3 x 7.5 inch
Notes Umsetzung der UHF-Kanäle auf VHF-Kanal 3 oder 4.
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 145.00 DM
Collectors' prices
Source of data Handbuch VDRG 1962/1963

Model page created by a member from A. See "Data change" for further contributors.
