VLF HF Receiver E 1800/3

VLF HF Receiver E 1800/3; Telefunken (ID = 2343032) Receiver-C
Use red slider bar for more.
VLF HF Receiver E 1800/3; Telefunken (ID = 2343032) Receiver-C
Telefunken: VLF HF Receiver E 1800/3 [Receiver-C] ID = 2343032 1200x361
Select picture or schematic to display from thumbnails on the right and click for download.
For model VLF HF Receiver E 1800/3, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Frontansicht; Gerät aus einer Privatsammlung

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1988 ?? Category: Commercial Receiver (may include amateur bands)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 40200/200 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details Radio Control (+Remote Wire etc)
Power type and voltage Line / Batteries (any type) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: VLF HF Receiver E 1800/3 - Telefunken Deutschland TFK,
Material Metal case
Shape Rack
Dimensions (WHD) 433 x 132 x 465 mm / 17 x 5.2 x 18.3 inch
Notes

Allwellenempfänger Telefunken / AEG-Telefunken / DASA E 1800/3: Frequenzbereich 10 kHz - 30 MHz, A1, A3, J3E (SSB); sieben mechanische ZF - Filter (Auswahl aus 0.1 / 0.15 / 0.3 / 0.6 / 1.0 / 1.5 / 3 / 6 / 10 kHz / +3 / -3 kHz) in der zweiten ZF. 100 Speicher.

Im Gegensatz zur Ur-Version E 1800 verbessertes HF-Frontend.

Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Mentioned in -- Original prospect or advert

Model page created by Martin Bösch. See "Data change" for further contributors.
