• Year
  • 1956
  • Category
  • Miscellaneous (Other, Various) - see notes
  • Radiomuseum.org ID
  • 227813

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Line (AC, UC or DC not known) / 110-240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Weitverkehr-Empfangsanlage TRANSRADIO ESt 127 Kw - Telefunken Deutschland TFK,
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 580 x 2026 x 500 mm / 22.8 x 79.8 x 19.7 inch
  • Notes
  • Die Anlage ESt127Kw dient zum Diversity- oder Einfach-Empfang von Telegraphie-,Telefonie-und Fernschreibsendungen. Anwendung bei Post, Wetterdienst,Polizei, Seefunk, Überseedienste und Presse. Bestückt mit mindestens 2 Empfängern E127.



  • Net weight (2.2 lb = 1 kg)
  • 230 kg / 506 lb 9.7 oz (506.608 lb)
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Rudolf Müller. See "Data change" for further contributors.
