Wien 2464 mattiert
Use red slider bar for more.
Telefunken: Wien 2464 [Radio] ID = 13660 402x282
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1963/1964 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: ECC85 ECH81 EBF89 ECL86 EM84 ECL86 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | Changer (Record changer) |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 220; 240 Volt |
| Loudspeaker | 4 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: Wien 2464 [mattiert] - Telefunken Deutschland TFK, |
| Material | Wooden case |
| Shape | Console with Push Buttons. |
| Dimensions (WHD) | 1200 x 780 x 380 mm / 47.2 x 30.7 x 15 inch |
| Notes | Rundfunk-Chassis = Allegro 2460, Stereo-NF-Verstärker mit 2 Endstufen je 3,5 W; Phono-Chassis = Telefunken TW504. |
| Net weight (2.2 lb = 1 kg) | 40 kg / 88 lb 1.7 oz (88.106 lb) |
| Price in first year of sale | 871.00 DM |
| External source of data | Erb |
| Source of data | Handbuch VDRG 1963/1964 |
