Scrambler TDS 2004 M
Telsy Elettronica e Telecomunicazioni S.p.A. ; Torino
- Country
- Italy
- Manufacturer / Brand
- Telsy Elettronica e Telecomunicazioni S.p.A. ; Torino
- Year
- 1981 ?
- Category
- Microphone or Pick-up element
- Radiomuseum.org ID
- 299210
Picture from manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: Scrambler TDS 2004 M - Telsy Elettronica e
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 190 x 100 x 330 mm / 7.5 x 3.9 x 13 inch
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Literature/Schematics (1)
- -- Original-techn. papers. (TDS 2004 M Instruction manual)
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
