• Country
• Czechoslovakia

• Manufacturer / Brand
• Tesla; Praha, Bratislava etc.

• Year
• 1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 76406

• • Brand: Supraphon

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 1R5T 1T4T 1T4T 1T4T 1S5T 1S5T DLL101

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 1.4 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch

• Power out
• 0.3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 508 B-2 - Tesla; Praha, Bratislava etc.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 435 x 272 x 180 mm / 17.1 x 10.7 x 7.1 inch

• Notes

• Siehe auch Exportausführung Tesla 508-B5 mit Wellenbereichen 3x KW, 1x MW
