Maj 620A

Maj 620A; Tesla; Praha, (ID = 83755) Radio

Maj 620A; Tesla; Praha, (ID = 94775) Radio

Maj 620A; Tesla; Praha, (ID = 94776) Radio
Maj 620A; Tesla; Praha, (ID = 94193) Radio Maj 620A; Tesla; Praha, (ID = 94194) Radio
Maj 620A; Tesla; Praha, (ID = 94195) Radio Maj 620A; Tesla; Praha, (ID = 369522) Radio
Maj 620A; Tesla; Praha, (ID = 369523) Radio Maj 620A; Tesla; Praha, (ID = 369524) Radio
Maj 620A; Tesla; Praha, (ID = 369525) Radio Maj 620A; Tesla; Praha, (ID = 369526) Radio
Maj 620A; Tesla; Praha, (ID = 369527) Radio Maj 620A; Tesla; Praha, (ID = 369528) Radio
Use red slider bar for more.
Maj 620A; Tesla; Praha, (ID = 94193) Radio
Tesla; Praha,: Maj 620A [Radio] ID = 94193 933x686
Select picture or schematic to display from thumbnails on the right and click for download.
For model Maj 620A, Tesla; Praha, Bratislava etc.:
Maj 620A.jpg

Country:  Czechoslovakia
Manufacturer / Brand:  Tesla; Praha, Bratislava etc.
Brand

Supraphon
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH21 EF22 EF22 EBL21 EM11 AZ11
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 2.8 W (unknown quality)
from Radiomuseum.org Model: Maj 620A - Tesla; Praha, Bratislava etc.
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 600 x 450 x 340 mm / 23.6 x 17.7 x 13.4 inch
Net weight (2.2 lb = 1 kg) 19 kg / 41 lb 13.6 oz (41.85 lb)
Mentioned in Ceskoslovenske Rozhlasove a Televizni Prijimace I a II

Model page created by Gabriel Toth. See "Data change" for further contributors.
