• Country
• Czechoslovakia

• Manufacturer / Brand
• Tesla; Praha, Bratislava etc.

• Year
• 1965 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 86058

• • Brand: Supraphon

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6Ж1П 6Ж1П 6Ж1П 6Ж1П 6Ж1П 6F32 EL84 AZ11 14TA31

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Millivoltmeter BM-384 [1965] - Tesla; Praha, Bratislava etc.

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 350 x 260 x 195 mm / 13.8 x 10.2 x 7.7 inch

• Notes
• Alternativ tubes: 6F32V instead of 6j1p.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• External source of data
• From my own collection

• Author
• Model page created by Gabriel Toth. See "Data change" for further contributors.
