Tabor II (2) 512073
Tesla; Praha, Bratislava etc.
- Country
- Czechoslovakia
- Manufacturer / Brand
- Tesla; Praha, Bratislava etc.
- Year
- 1956/1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 274167
-
- Brand: Supraphon
gesperrt
gesperrt
gesperrt
- Number of Tubes
- 9
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 150; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Power out
- 8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Tabor II 512073 - Tesla; Praha, Bratislava etc.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 700 x 480 x 500 mm / 27.6 x 18.9 x 19.7 inch
- Notes
-
Tabor II (2) 512073
Siehe auch Tabor ! 512070, Tabor II 512074, Tabor II 512072
KW 13,9 - 20 m und 24,6 - 52 m (Skalabeschriftung)
2 Lautsprecher mit jeweils 200 mm Durchmesser
- Net weight (2.2 lb = 1 kg)
- 35 kg / 77 lb 1.5 oz (77.093 lb)
- Mentioned in
- E.Kottek Ceskoslovenské roshlasové a lelevizni prijimace SNTL 1964
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
