Transistor-Prüfgerät BM429

• Country
• Czechoslovakia

• Manufacturer / Brand
• Tesla; Praha, Bratislava etc.

• Year
• 1960 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 110292

• • Brand: Supraphon

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECF82 ECC83 ECC85 ECC83 EZ81 11TA31

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Transistor-Prüfgerät BM429 - Tesla; Praha, Bratislava etc.

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 310 x 245 x 210 mm / 12.2 x 9.6 x 8.3 inch

• Notes
• Prüfgerät für Transistoren.

• Net weight (2.2 lb = 1 kg)
• 9.5 kg / 20 lb 14.8 oz (20.925 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Documents regarding this model

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
