Tasma 135

Tasma 135; Thom & Smith Pty. (ID = 1590637) Radio
Tasma 135; Thom & Smith Pty. (ID = 2379520) Radio Tasma 135; Thom & Smith Pty. (ID = 2379521) Radio
Tasma 135; Thom & Smith Pty. (ID = 2379522) Radio Tasma 135; Thom & Smith Pty. (ID = 2030298) Radio
Use red slider bar for more.
Tasma 135; Thom & Smith Pty. (ID = 2379520) Radio
Thom & Smith Pty.: Tasma 135 [Radio] ID = 2379520 1400x2064
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tasma 135, Thom & Smith Pty. Ltd.(Tasma);Mascot, NSW:
From brochure.

Country:  Australia
Manufacturer / Brand:  Thom & Smith Pty. Ltd.(Tasma);Mascot, NSW
Brand

Tasma
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 57 58 57 59 80
Main principle Superheterodyne (common); ZF/IF 164/178 kHz; 1 AF stage(s); Anode bend detection
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Tasma 135 - Thom & Smith Pty. Ltd.Tasma;
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes The higher I.F. was used only on radios sold in Western Australia and New Zealand.
Price in first year of sale 28.00 Aus£
Literature/Schematics (1) - - Manufacturers Literature (Tasma Service Data, Drawing No. 49.)
Literature/Schematics (2) Radio Trade Annual of Australia (6th Edition 1938, Page 344.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
