For model 932, Titan, ES radiotovarna, Praha

Country:  Czechoslovakia
Manufacturer / Brand:  Titan, ES radiotovarna, Praha
Year: 1932/1933 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: E424N B443 1801
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 127/220 Volt
Loudspeaker Magnetic loudspeaker (reed) of high quality (4 magnet poles).
Power out
from Radiomuseum.org Model: 932 - Titan, ES radiotovarna, Praha
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Dimensions (WHD) 371 x 470 x 207 mm / 14.6 x 18.5 x 8.1 inch
External source of data Radiojournal (CZ) 5+6/1990

Model page created by Gabriel Toth. See "Data change" for further contributors.
