Titan Tiny

K.G.H. Pty., Ltd. (Titan); Bondi Junction, Sydney, NSW

Data
Forum
Pictures
Collections

  • Year
  • 1951
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 193004
    • alternative name: K.G.H Pty. Ltd. (KGH), Bondi Junction, Sydney

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 1 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Bakelite or Plastics (type unknown)
  • from Radiomuseum.org
  • Model: Titan Tiny - K.G.H. Pty., Ltd. Titan; Bondi
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 6.5 x 4.25 x 4.25 inch / 165 x 108 x 108 mm
  • Notes

  • Although this radio uses a power transformer it only supplies the valve heaters and dial lights. The 6X4 is connected as a half wave rectifier and rectifies the mains directly. The chassis is connected to one side of the mains and may be "live". We do NOT always state such cases - since often the uploader does not know.

    Available in a choice of 8 colours. Black & walnut cost 18gns (£18.9). Extra for other colours.

  • Net weight (2.2 lb = 1 kg)
  • 5 lb (5 lb 0 oz) / 2.270 kg
  • Price in first year of sale
  • 18.90 AU£
  • Circuit diagram reference
  • Australian Official Radio Service Manual Vol. XI
  • Mentioned in
  • The Sydney Herald (NSW), June 3, 1951, Page 12.
  • Author
  • Model page created by Stuart Irwin. See "Data change" for further contributors.
