Model Three

Tivoli Audio; Cambridge, MA

Data
Forum
Pictures
Collections

  • Year
  • 2003 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 307807

 Technical Specifications

  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / DC: 12 / AA: 1 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Model Three - Tivoli Audio; Cambridge, MA
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 8.375 x 4.5 x 5.25 inch / 213 x 114 x 133 mm
  • Notes

  • The Model Three is very similar to a Model One but with an analog clock and alarm.

    Additional features include:

    • Quartz analog clock
    • Wake-to-radio or buzzer
    • Sleep timer
    • Clock backup battery AA: 1 x 1.5 Alkaline.
    • Receiver powered by either 60 Hz 120 V or 50Hz 230 V to 12 V DC power adaptor.
    • 3" full-range driver.
    • Able to connect with a matching passive external speaker connected by a cable to provide true stereo sound as featured with the Model Two.
  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Price in first year of sale
  • 299.00 Euro
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Owners Manual)
  • Author
  • Model page created by Gianfranco Mischis. See "Data change" for further contributors.
