Violetta W201/II

Violetta W201/II; Tonfunk GmbH; (ID = 467230) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1527285) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1527806) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1528206) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1528207) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1528208) Radio

Violetta W201/II; Tonfunk GmbH; (ID = 1528210) Radio
Violetta W201/II; Tonfunk GmbH; (ID = 880462) Radio Violetta W201/II; Tonfunk GmbH; (ID = 880461) Radio
Violetta W201/II; Tonfunk GmbH; (ID = 498959) Radio Violetta W201/II; Tonfunk GmbH; (ID = 2121217) Radio
Use red slider bar for more.
Violetta W201/II; Tonfunk GmbH; (ID = 880462) Radio
Tonfunk GmbH;: Violetta W201/II [Radio] ID = 880462 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Violetta W201/II, Tonfunk GmbH; Karlsruhe

Country:  Germany
Manufacturer / Brand:  Tonfunk GmbH; Karlsruhe
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EC92 ECH81 EF41 EF41 EM4 EABC80 EL41
Semiconductors (the count is only for transistors) B250C85
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Violetta W201/II - Tonfunk GmbH; Karlsruhe
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 440 x 280 x 230 mm / 17.3 x 11 x 9.1 inch
Notes

MW Ortssender-Taste

UKW: Selbstschwingende Mischstufe, ZF-Verstärker 3-stufig, Ratiodetektor.
Skala: goldfarbig

Siehe auch Tonfunk Violetta W201/I mit dunkler Skala, anderem ZF-Verstärker und EB41/EAF42 statt der EABC80.

Modell der Zwischensaison 1952/53, im Grosshandelskatalog nur mit Violetta W201 bezeichnet.

Price in first year of sale 258.00 DM
External source of data Rutishauser/EE
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Elektron Taschenbuch, 1952
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) HdB d.Rdf-& Ferns-GrH 1953/54 (Modell der Zwischensaison 1952/53, S.140)


All listed radios etc. from Tonfunk GmbH; Karlsruhe
