11L-855F

11L-855F; Toshiba Corporation; (ID = 1704850) Radio

11L-855F; Toshiba Corporation; (ID = 1704851) Radio

11L-855F; Toshiba Corporation; (ID = 1704853) Radio

11L-855F; Toshiba Corporation; (ID = 1704855) Radio

11L-855F; Toshiba Corporation; (ID = 1704857) Radio

11L-855F; Toshiba Corporation; (ID = 1704858) Radio

11L-855F; Toshiba Corporation; (ID = 1704860) Radio

11L-855F; Toshiba Corporation; (ID = 1704862) Radio
11L-855F; Toshiba Corporation; (ID = 1704632) Radio
Use red slider bar for more.
11L-855F; Toshiba Corporation; (ID = 1704632) Radio
Toshiba Corporation;: 11L-855F [Radio] ID = 1704632 700x575
Select picture or schematic to display from thumbnails on the right and click for download.
For model 11L-855F, Toshiba Corporation; Tokyo:
Photo from manual cover.

Country:  Japan
Manufacturer / Brand:  Toshiba Corporation; Tokyo
alternative name

Shibaura Engineering Works
Brand
Tokyo Shibaura
Year: 1969 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: 2SA506 or. 2SA240 2SA506 or. 2SA240 2SA71 2SA71 2SA71 2SA71 2SA71 2SB54 2SB56 2SB364 2SB364 1S86 1N60
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / C: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
Power out 1 W (max.)
from Radiomuseum.org Model: 11L-855F - Toshiba Corporation; Tokyo
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 9.25 x 7.5 x 2.37 inch / 235 x 191 x 60 mm
Notes

Frequency Range:

AM:  530-1650 kHz
SW:  2 - 6 MHz
FM: 87.5-108 MHz

Diode 1N60 is 5 times present.

See also Toshiba 11L-855FL with LW, MW and FM.

Price in first year of sale 54.00 US$

Model page created by Daniel Rosha. See "Data change" for further contributors.
