Solid State FM/AM 7H-896F (Japan 710)

Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 963000) Radio
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136673) Radio Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136675) Radio
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136677) Radio Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 645312) Radio
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136674) Radio Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136676) Radio
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136678) Radio Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136679) Radio
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136680) Radio
Use red slider bar for more.
Solid State FM/AM 7H-896F ; Toshiba Corporation; (ID = 2136673) Radio
Toshiba Corporation;: Solid State FM/AM 7H-896F [Radio] ID = 2136673 1400x789
Select picture or schematic to display from thumbnails on the right and click for download.
For model Solid State FM/AM 7H-896F (Japan 710), Toshiba Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Toshiba Corporation; Tokyo
alternative name

Shibaura Engineering Works
Brand
Tokyo Shibaura
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 2SC784 2SC394 2SC380 2SC380 2SC380 2SC372 1N60 1N60 1N60 2SC515 1S34 1S352 1S34 1S34 1S1943
Main principle Super-Heterodyne (Super in general)
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 120 or 115; 230 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Solid State FM/AM 7H-896F - Toshiba Corporation; Tokyo
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes Toshiba 7H-896F, Solid State FM/AM, 7 Transistor AM/FM 2 Band;
AM: 530 - 1600 kHz,
FM: 87.5 - 108 MHz,
tone high/low control.
USA models 120V 60Hz , other countries 115/230V 50Hz
