- Country
- Italy
- Manufacturer / Brand
- Trevi S.p.A.; Rimini
- Year
- 1985 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 361133
- Number of Transistors
- 12
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 50 Hz, 220 / C: 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 910 - Trevi S.p.A.; Rimini
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 228 x 140 x 50 mm / 9 x 5.5 x 2 inch
- Notes
-
The scale indicates FM from 88 to 108 MHz, AM 550 to 200 m.
Frontally, the scale horizontally, with a red tuning LED to the left and below, on the same line, two metal selectors: radio on/off, AFC on/off and a linear control, also in metal, for the tone; to the side two wheels for tuning and volume. Above only the telescopic antenna, fully rotating, external at rest, 5 sections, 72 cm. On the rear panel the FM/AM selector, the earphone socket and the power supply socket, as well as access to the battery compartment.
Ferrite antenna of only 5.3 cm. Rigid, metal handle with partial plastic coating, full travel.
Twin unit of the Sinudyne SR-356.
Dimensions including the protrusions and weighing without the batteries.
- Net weight (2.2 lb = 1 kg)
- 0.750 kg / 1 lb 10.4 oz (1.652 lb)
- Author
- Model page created by Felice Nicolini. See "Data change" for further contributors.
