• Year
  • 1963/1964 ?
  • Category
  • Amateur-Receiver (amateur bands, may include broadcast bands)
  • Radiomuseum.org ID
  • 96030
    • alternative name: Trio Corp.
    • Brand: Jennen

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 13
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: JR-60 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 17 x 7.625 x 10.125 inch / 432 x 194 x 257 mm
  • Notes
  • Trio Communications Receiver JR-60.
    Coverage 520 kHz to 30 MHz in 4 bands, additional 6-m-band (US model - 48-54 MHz) or 2-m-band (European model - 142-148 MHz) with double conversion; AM, CW (BFO); Q-Multiplier.
    Improved version of Trio-Kenwood 9R59 receiver:
    6-m-band-version also sold as Lafayette HE-80,
    2-m-band-version also sold as Trio ER-202 and Jennen JR-102.
  • Net weight (2.2 lb = 1 kg)
  • 23.5 lb (23 lb 8 oz) / 10.669 kg
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model is part of the collections of the following members.

 Forum

Forum contributions about this model: Kenwood, Trio-: JR-60

Threads: 1 | Posts: 7

Hallo RMorg Gemeinde,

Der Schaltplan zum Modell ist nicht so scharf das man den Wert erkennen kann.

Diser Quarz fehlt und ich brauche den Wert zweck`s Neubeschaffung.Danke und

MfG

K.R.

Attachments

Klemens Rhode, 29.Aug.12
