Compact Disc Player DP-1080

Kenwood, Trio-Kenwood Inc.; Komagane

  • Year
  • 1997
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 295052
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 220/240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player DP-1080 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 440 x 93 x 375 mm / 17.3 x 3.7 x 14.8 inch
  • Notes
  • CD Player with DPAC, DAC 1 bit D/A with DPAC, 8-sampling digital filter, DAPC (digital drive shaft control), CCRS aut/recording, cd cassette recorder, center mechanism, automatic space function, memory and musical calendar of 20 songs, headphones in, output analog, random reproduction, remote control, frequency response 8Hz-20 kHz +- 1,0 dB, signal noise ratio » 94 dB, total harmonic distortion « 0,005%, channels separation » 85 dB, crying & floating  imeasurable, converter D/A 1 bit,oversampling fs.

  • Net weight (2.2 lb = 1 kg)
  • 4 kg / 8 lb 13 oz (8.811 lb)
  • Mentioned in
  • Catalogues Kenwood 1997, Model Page 24
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
