Quartz PLL Direct Drive Turntable KD-600

• alternative name: Trio Corp.
• Brand: Jennen

Unlike most complete turntables, the KD-600 was deliberately sold without a tonearm, headshell or cartridge. Kenwood supplied interchangeable armboards, including one intended for SME arms and another for Ortofon arms. This allowed the purchaser to fit the tonearm of their choice.

One of the KD-600's major features was Kenwood's ACRB (Anti-Resonance Compression Base). Rather than using an ordinary wooden or plastic plinth, Kenwood used a very heavy composite structure designed to suppress vibration and resonance. The heavy base, 2.6 kg platter, and substantial main bearing are key parts of the KD-600's design.

Quartz PLL direct drive turntable.
2 speeds (33 & 45 rpm)
Platter 300mm, die-cast aluminum, 2.6 kg
Power consumption 35 watts
Without tonearm.

Kenwood Plattenspieler mit quarz-geregeltem-Direktantrieb Modell KD-600.
2 Geschwindigkeiten (33 & 45 U/Min)
Plattenteller 300mm, Alu-Druckguss, 2,6 kg
Leistungsaufnahme 35 Watt
OhneTonarm

In questo link sono elencati 925 modelli, di cui 860 con immagini e 256 con schemi.
Elenco delle radio e altri apparecchi della Kenwood, Trio-Kenwood Inc.; Komagane
