Stereo Integrated Amplifier KA-4010
Kenwood, Trio-Kenwood Inc.; Komagane
- Country
- Japan
- Manufacturer / Brand
- Kenwood, Trio-Kenwood Inc.; Komagane
- Year
- 1989 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 277758
-
- alternative name: Trio Corp.
- Brand: Jennen
Q: Kenwood, Service-Manual, printesd, 1989-6
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 190 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Integrated Amplifier KA-4010 - Kenwood, Trio-Kenwood Inc.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 440 x 123 x 345 mm / 17.3 x 4.8 x 13.6 inch
- Notes
-
Ausgangsleistung: 2 X 95 Watt bei 4 Ohm.
Frequenzgang: 20 - 70 kHz.
Eingänge:CD, Tuner; Tape, AUX, Phono schaltbar MM und MC.
Ausgänge: Phono, AUX.
Schaltbare Tiefbassanhebung (+3db bei 100 Hz).
- Net weight (2.2 lb = 1 kg)
- 8.8 kg / 19 lb 6.1 oz (19.383 lb)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
