Stereo Integrated Amplifier KA-9150

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958119) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958120) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958121) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958122) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958123) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958127) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958133) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958136) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958138) Ampl/Mixer

Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958139) Ampl/Mixer
Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958147) Ampl/Mixer Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958150) Ampl/Mixer
Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958151) Ampl/Mixer Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958152) Ampl/Mixer
Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958153) Ampl/Mixer Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958154) Ampl/Mixer
Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958155) Ampl/Mixer
Use red slider bar for more.
Stereo Integrated Amplifier KA-9150; Trio-Kenwood (ID = 1958147) Ampl/Mixer
Trio-Kenwood: Stereo Integrated Amplifier KA-9150 [Ampl/Mixer] ID = 1958147 1400x489
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Integrated Amplifier KA-9150, Trio-Kenwood Electronic Inc.; Komagane:
Ebay Auction

Country:  Japan
Manufacturer / Brand:  Trio-Kenwood Electronic Inc.; Komagane
alternative name

Trio Corp.
Brand
Jennen
Year: 1978 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-120/220-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 180 W (undistorted)
from Radiomuseum.org Model: Stereo Integrated Amplifier KA-9150 - Trio-Kenwood Electronic Inc.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 149 x 384 mm / 16.9 x 5.9 x 15.1 inch
Notes

Kenwood Integrated Amplifier Model KA-9150.
Power output: 90 watts per channel into 8Ω (stereo), 20-20000Hz
Frequency response: 7Hz to 50kHz
Total harmonic distortion: 0.03%
Damping factor: 50
Input sensitivity: 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 83dB (MM), 100dB (line)
Output: 150mV (line), 30mV (DIN)
Tone Controls:
Bass +/-7,5dB at 100Hz
Treble +/-7,5dB at 10000Hz
Loudness
Subsonic Filter 18Hz, 12dB/Oct
High Filter 8000Hz, 12dB/Oct
Speaker load impedance: 4Ω to 16Ω
AC Outlets:
2x Switched, 1x Unswitched
Power Consumption 660 Watts
Finish: Black

Net weight (2.2 lb = 1 kg) 16.7 kg / 36 lb 12.5 oz (36.784 lb)
Mentioned in - - Manufacturers Literature (Service Manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
