TR-7600; Trio-Kenwood (ID = 915545) Amat TRX
Trio-Kenwood: TR-7600 [Amat TRX] ID = 915545 933x405
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR-7600, Trio-Kenwood Electronic Inc.; Komagane

Country:  Japan
Manufacturer / Brand:  Trio-Kenwood Electronic Inc.; Komagane
alternative name

Trio Corp.
Brand
Jennen
Year: 1979 ?? Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) 52:
Main principle Superhet, double/triple conversion
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TR-7600 - Trio-Kenwood Electronic Inc.;
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 160 x 60 x 260 mm / 6.3 x 2.4 x 10.2 inch
Notes Kenwood Mobile VHF-FM-Transceiver TR-7600.
Frequency range: 144-146 MHz; Pout: 10 W.
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)

Model page created by Iven Müller. See "Data change" for further contributors.
